DINION THERMAL
High-Sensitivity Thermal IP Camera (VGA, 9mm)
This thermal IP camera provides high-sensitivity thermal images using an un-cooled vanadium oxide microbolometer that delivers outstanding image quality. The camera is designed to combine the benefits of thermal imaging with the market leading Intelligent Video Analytics from Bosch.
There is no need for natural or artificial lighting of the area of interest. The camera produces crisp and clear images day and night, even in challenging environments with smoke, dust, haze or fog.
Key Features:
- High-sensitivity thermal imaging for 24/7 performance.
- Built-in Intelligent Video Analytics for reliable detection.
- Operates in complete darkness and challenging weather.
- Available in QVGA or VGA resolution with multiple lens options.
- Robust outdoor housing for demanding environments.
| Sensor | Un-cooled vanadium oxide microbolometer |
| Resolution | VGA (640x480) or QVGA (320x240) |
| Frame Rate | Up to 60 fps |
| Lens Options | 7.5mm, 9mm, 16.7mm, 19mm, 35mm, 65mm |
| Video Compression | H.264, M-JPEG |
| Video Analytics | Intelligent Video Analytics (IVA) |
| Local Storage | microSDHC/microSDXC card slot (up to 2 TB) |
| Operating Temperature | -50°C to +55°C |
| Environmental | IP66, NEMA-4X |
- Sensor Un-cooled vanadium oxide microbolometer
- Resolution VGA (640x480) or QVGA (320x240)
- Frame Rate Up to 60 fps
- Lens Options 7.5mm, 9mm, 16.7mm, 19mm, 35mm, 65mm
- Video Compression H.264, M-JPEG
- Video Analytics Intelligent Video Analytics (IVA)
- Local Storage microSDHC/microSDXC card slot (up to 2 TB)
- Operating Temperature -50°C to +55°C
- Environmental IP66, NEMA-4X
