VESPER
Professional-Grade Micro UAV - ISR 320-MIL-ID
The Vesper UAV from Vantage Robotics provides field operators with American-made ISR, extended flight time, unmatched low-light performance, and a 3-axis stabilized tri-sensor payload. This complete aerial reconnaissance system was designed to solve the pain points of operators utilizing aerial data collection in the field today.
Our light, rugged, and truly portable stealth drone is backpack-ready, easy to use, and has been tested with thousands of flight hours. Vesper's modular design and uncompromising build quality meet the needs of a range of mission-critical operations at a moment's notice.
| Capable Camera | 48× combined zoom, 4K EO / 320p thermal |
| Exceptional Endurance | Up to 40 min flight time |
| Portable | < 3.5 kg in field configuration with 2 spare batteries |
| Stealthy | <40 dB from 40m distance and 40m above ground level |
| Modular | Quick assembly and reconfiguration |
| Extensive Range | -2.5 km GCS, 0.5 km in Suburban / Urban Environments |
| Secure | AES-256 encryption / Made in USA / NDAA compliant |
| Aircraft | Flight time: 40–45 min continuous forward flight 20–25 min using Shrouded Rotor Set Weight: approx. 750 g with battery installed Max speed: 55–65 kph Noise: <40 dBA at 40 m slant distance, 40 m AGL Wind operation: 20 kph Temperature range: –20° to 45°C Ingress protection: IP53 Downward-facing sensor for obstacle avoidance |
| Gimbal & Camera | Dual EO sensors + thermal, 3-axis stabilized gimbal Gimbal pitch: +30° to –90° Dual 4K Sony IMX334 EO sensors (3840×2160p, 8MP still) 48× combined optical & digital zoom 6 mm f/1.0 navigation lens 25 mm f/2.4 telephoto lens 1080p or 4K MPEG-4 video recording Thermal sensor: 320×240p |
| Security | Designed, sourced, and built in USA AES-256 encryption on communications & data storage Bonded construction prevents tampering Blue UAS approved |
| Portability | IP67 waterproof field case 1 m drop in case Total system weight: approx. 3 kg packed in field case Watertight, dust-proof, dent-proof transport case with foam-lined interior |
| Modularity | Battery attaches magnetically and swaps in seconds Multiple rotor assembly options: Shrouded or Recon Rotor assemblies swappable in field without tooling Field-replaceable gimbal can be swapped in minutes |
| Communications | ~1.5 km in rural environments ~0.5 km in suburban/urban environments <0.5 km in RF congested conditions 2.4 GHz GCSS & UAV radios WiFi for short-range rapid data transfer to GCS |
- Capable Camera 48× combined zoom, 4K EO / 320p thermal
- Exceptional Endurance Up to 40 min flight time
- Portable < 3.5 kg in field configuration with 2 spare batteries
- Stealthy <40 dB from 40m distance and 40m above ground level
- Modular Quick assembly and reconfiguration
- Extensive Range -2.5 km GCS, 0.5 km in Suburban / Urban Environments
- Secure AES-256 encryption / Made in USA / NDAA compliant
-
Aircraft
Flight time: 40–45 min continuous forward flight
20–25 min using Shrouded Rotor Set
Weight: approx. 750 g with battery installed
Max speed: 55–65 kph
Noise: <40 dBA at 40 m slant distance, 40 m AGL
Wind operation: 20 kph
Temperature range: –20° to 45°C
Ingress protection: IP53
Downward-facing sensor for obstacle avoidance -
Gimbal & Camera
Dual EO sensors + thermal, 3-axis stabilized gimbal
Gimbal pitch: +30° to –90°
Dual 4K Sony IMX334 EO sensors (3840×2160p, 8MP still)
48× combined optical & digital zoom
6 mm f/1.0 navigation lens
25 mm f/2.4 telephoto lens
1080p or 4K MPEG-4 video recording
Thermal sensor: 320×240p -
Security
Designed, sourced, and built in USA
AES-256 encryption on communications & data storage
Bonded construction prevents tampering
Blue UAS approved -
Portability
IP67 waterproof field case
1 m drop in case
Total system weight: approx. 3 kg packed in field case
Watertight, dust-proof, dent-proof transport case with foam-lined interior -
Modularity
Battery attaches magnetically and swaps in seconds
Multiple rotor assembly options: Shrouded or Recon
Rotor assemblies swappable in field without tooling
Field-replaceable gimbal can be swapped in minutes -
Communications
~1.5 km in rural environments
~0.5 km in suburban/urban environments
<0.5 km in RF congested conditions
2.4 GHz GCSS & UAV radios
WiFi for short-range rapid data transfer to GCS
